Actnow 100mm Rubber Flood Test Puddle Flange

$14.50 AUD
$14.50 AUD
Shipping calculated at checkout.

Prices shown exclusive of GST.

EMPTY DOM REMOVE PROTECTOR
Actnow 100mm Rubber Flood Test Puddle Flange is a flexible neoprene drainage flange with an intact base for temporarily sealing a 100mm PVC drainage outlet during flood testing. It is
  • The intact base seals the drainage outlet for the TDS-specified 24-hour flood test.
  • Flexible neoprene rubber moulds to the PVC pipe for controlled drainage detailing.
  • The flange provides a membrane termination between the concrete floor and drainage outlet.
  • Compatible with most waterproofing membranes, joint sealants and MS bond breakers
  • Recessed installation provides a flush membrane transition
  • Flexible, tough, tear resistant, low odour and non-hazardous as stated in the TDS
  • 1. Allow new concrete to cure for at least 28 days, cut the PVC pipe flush with the slab, then clean and dry the substrate.
  • 2. Solvent-wipe the flange and recess it so it sits flush with the prepared substrate.
  • 3. Prime the substrate with a compatible primer. Prime the internal PVC pipe wall with ACTFLEX Superbond 007 or an approved PVC bonding agent and allow it to dry.
  • 4. Install the flange-to-substrate transition with ACTFLEX 75FC or V-Tech MS. Apply hand pressure so the sealant extrudes at least 10mm beyond the flange edge, tool off excess and allow it to cure.
  • 5. Apply the waterproofing membrane over the flange and at least 50mm down the flange wall in accordance with the membrane manufacturer’s specification.
  • 6. After the membrane has cured, flood the area with water for 24 hours before protection or screeding.
  • 7. Release the water by carefully cutting an X incision in the flange base without cutting the flange walls.
  • Material: Neoprene flexible rubber
  • Outlet: 100mm PVC drainage outlet
  • Base: Intact moulded base for flood testing
  • Flood test duration: 24 hours
  • Application temperature: 10–26°C
  • Minimum membrane downturn: 50mm
  • Internal falls: 1:80
  • External falls: 1:100
  • Storage: Cool, dry and well ventilated at 10–26°C and 50% RH; protect from sunlight

Complete Your System

  • Actnow 100mm rubber flood test puddle flange with sealed base
    Current product Actnow 100mm Rubber Flood Test Puddle Flange $14.50 AUD In stock
  • Forspec ACTFLEX 75FC grey polyurethane joint sealant 600ml sausage
    System component ACTFLEX 75FC – Polyurethane Sealant $14.50 AUD In stock
System total

Applications

Bathroom
Shower
Laundry
Internal Wet Areas
Balcony
Rooftop
External Waterproofing

Technical Specifications

Key technical properties of this product. Refer to the Technical Data Sheet for complete installation and performance information.

ClassificationClosed-base rubber flood test puddle flange
Suitable SubstratesPrepared concrete floors with 100mm PVC drainage outlets
Internal / External UseInternal and external
Compliance Stated in TDSCodeMark CM40377; AS 3740:2021 Fig. 4.3.1; AS 4654.2 Fig. 2.8.4; NCC 2022 F1D5 and H2D8
Australian Design Registration201814766 (as stated in TDS)
